Major Service Kit for JMP Marine Cummins Engine Cooling Raw Water / Seawater Pump JPR-C1900, Cummins 3049158, 3074540, Gilkes 44955-052.

PLEASE NOTE:
Major Kit #JSK0122 can be used to service both JMP Marine & OEM / Genuine engine cooling raw water pumps. JMP Marine uses the highest grade of materials in manufacturing all their parts & components which ensures the longest-lasting performance product for the customer.

Major Service Kit #JSK0122 Includes (All Internal Parts):

BER0037 (ROLLER BEARING) - QTY:1
BER0038 (ROLLER BEARING) - QTY:1
BOL011001 (SLOTTED NUT) - QTY:1
BOL0111 (LOCK WASHER) - QTY:1
BOL0112 (FLAT WASHER) - QTY:1
BOL011301 (HEX BOLT) - QTY:1
BOL0117 (SET SCREW) - QTY:1
IMP002601 (BRONZE IMPELLER) - QTY:1
MCSSET0009 (MECHANICAL SEAL SET) - QTY:1 (*Part of Seal Kit #JMK0001)
NIP0008 (PLUG, DRAIN) - QTY:1
NIP0009 (PIN, GREASE) - QTY:2
ORG0023 (O-RING) - QTY:2
ORG0024 (O-RING) - QTY:1
ORG0029 (O-RING) - QTY:1 (*Part of Seal Kit #JMK0001)
PORT001G (PORT PLATE) - QTY:2
RET0020 (OIL SEAL) - QTY:1 (*Part of Seal Kit #JMK0001)
RET0022 (OIL SEAL) - QTY:1 (*Part of Seal Kit #JMK0001)
RIG0002 (RING, DISTANCE) - QTY:1
SHA0054 (SHAFT) - QTY:1
SNP0016 (SNAP RING) - QTY:1
SNP0018 (SNAP RING) - QTY:1
SPC0003 (SPACER) - QTY:1 (*Part of Seal Kit #JMK0001)
SPC0005 (COLLAR SEAL) - QTY:1
SPC0009 (COLLAR SEAL) - QTY:1
SPC0010 (SHIM, 0.3mm) - QTY:2
SPC0011 (SHIM, 0.1mm) - QTY:2

JSK0122 Approx Total Lbs: 29 LBS / 14.55 kg

Services JMP Marine Cummins Replacement Engine Cooling Raw Water Pump & OEM / Genuine . . .

JMP Marine Engine Cooling Raw Water Pump: #JPR-C1900, JPR-C1900G
#JPR-C1900 & C1900G Replaces Cummins Pump P/N: 3049158, 3074540
#JPR-C1900 & C1900G Replaces Gilkes Pump: 44955-052, 44955052
#JPR-C1900 & C1900G good for Engine Models: K19, KT19M, KTA19M, KTA19M3/M6, KTA19-D(M), KTA19-D(M1)
